SPECIFICATIONS BIOLOGICAL SEWAGE TREATMENT UNITS
- Type approval form Lloyd’s and Netherlands Shipping Inspection, MED IMO/Marpol certificate.
- Competitive standard product range.
- Standard systems in stock.
- Custom built for any capacity up to 850 persons capacity.
- Short, reliable delivery time by own, guaranteed by our Amsterdam production facility
- The most compact biological process; low sludge production, simple and reliable process control by our “Fixed Activated Sludge Technology” (FAST®).
- Integration with our own produced Ejector Vacuum Toilet System possible.
- Integration with any maker Vacuum Collecting System possible.
- Cost effective and reliable; one supplier for the complete installation.
- Worldwide around the clock service and repair available by our own engineers.
| Specifications Biological Sewage Treatment units, MSD-II series standard units | ||||||
|---|---|---|---|---|---|---|
| Type ** | Dimensions L x W x H |
Nos. of person |
Weight | Hydraulic load |
Organic load |
Power consumption |
| MSD-III/10 | 1,310 x 1,000 x 1,599 |
11 | 490 kg | 0,83 m³ / day |
0,44 kg BOD / day |
3 kW |
| MSD-III/20 | 2,100 x 1,000 x 1,790 |
23 | 720 kg | 1,65 m³ / day |
0,92 kg BOD / day |
4 kW |
| MSD-III/30 | 2,100 x 1,300 x 1,790 |
35 | 850 kg | 2,48 m³ / day |
1,40 kg BOD / day |
4 kW |
| MSD-III/40 | 2,100 x 1,550 x 1,790 |
47 | 1.015 kg | 3,30 m³ / day |
1,90 kg BOD / day |
5 kW |
| MSD-III/50 | 2,450 x 1,550 x 1,790 |
58 | 1.090 kg | 4,10 m³ / day |
2,32 kg BOD / day |
5 kW |
| MSD-III/60 | 1.270 x 1,550 x 1,790 |
70 | 1.200 kg | 4,95 m³ / day |
2,80 kg BOD / day |
5 kW |
| MSD-III/70 | 3.200 x 1,550 x 1,790 |
82 | 1.380 kg | 5,78 m³ / day |
3,30 kg BOD / day |
5 kW |
| MSD-III/80 | 2,200 x 1,600 x 2,402 |
94 | 1.680 kg | 6,60 m³ / day |
3,76 kg BOD / day |
6 kW |
| MSD-III/100 | 2,500 x 1,600 x 2,402 |
117 | 1.870 kg | 8,25 m³ / day |
4,68 kg BOD / day |
7 kW |
| MSD-III/120 | 2,900 x 1,600 x 2,402 |
141 | 2.130 kg | 9,89 m³ / day |
5,64 kg BOD / day |
7 kW |
| MSD-III/140 | 3,300 x 1,600 x 2,402 |
164 | 2.355 kg | 11,54 m³ / day |
6,56 kg BOD / day |
8 kW |
| MSD-III/160 | 3,700 x 1,600 x 2,402 |
188 | 2.550 kg | 13,22 m³ / day |
7,52 kg BOD / day |
8 kW |
| MSD-III/200 | 3,700 x 1,990 x 2,408 |
235 | 3.620 kg | 16,50 m³ / day |
9,40 kg BOD / day |
10 kW |
| MSD-III/240 | 4,190 x 2290 x 2,408 |
282 | 4.620 kg | 19,79 m³ / day |
11,28 kg BOD / day |
11 kW |
| MSD-III/280 | 4,190 x 2,590 x 2,408 |
330 | 4.816 kg | 23,11 m³ / day |
13,02 kg BOD / day |
11 kW |
| MSD-III/320 | 4,210 x 2,870 x 2,408 |
377 | 5.385 kg | 26,40 m³ / day |
15,08kg BOD / day |
11 kW |
| MSD-III/400 | 4,810 x 2,870 x 2,408 |
471 | 6.860 kg | 33,01 m³ / day |
18,84 kg BOD / day |
11 kW |
